Indoor Cat6 FTP Cable
This is indoor Cat6 FTP network cable, equipped with PE cross‑separator, foil single‑shielded structure and high‑purity oxygen‑free copper conductors. It supports Gigabit network transmission with excellent anti‑electromagnetic‑interference performance, suitable for indoor Gigabit network cabling projects.
1.Key Features
• High-purity oxygen-free copper conductors reduce signal attenuation and ensure stable gigabit network transmission
• PE cross separator separates four twisted pairs, reducing crosstalk between pairs
• Aluminum foil shielding resists external electromagnetic interference, suitable for areas with strong interference indoors
• HDPE insulation with multiple jacket options, adaptable to different indoor installation requirements
• Raw materials meet ROHS environmental standards, controlling harmful substances
• Clearly defined installation pull strength and bending radius, making installation easier
2.Materials & Construction
• Built with industry-standard materials and manufacturing processes for export-ready quality
3.Product Advantages
• Cost-effective solution for engineering and project bulk purchasing
• OEM/ODM customization and stable supply chain support
| Item | Parameter |
|---|---|
| Product Model | Indoor Cat6 FTP Cable |
| Compliance Standard | ISO/IEC 11801, ANSI/TIA‑568.2‑D, YD/T1019‑2013 |
| Conductor Spec. | 23AWG, high‑purity oxygen‑free copper (99.9% purity) |
| Insulation Material | HDPE |
| Filler Material | PE cross‑separator |
| Outer Jacket Material | PVC, LSZH, TPU optional |
| Operating Temperature | ‑20℃ ~ 75℃ |
| Packing Spec. | 305 m per box |
| Max Installation Tension | 110N |
| Min Installation Bending Radius | 8 × cable outer diameter |
| Environmental Standard | RoHS compliant |
| Cable Appearance | Grey outer jacket |
1.Applications
• Indoor gigabit structured cabling for office buildings and commercial buildings
• Network cabling for computer rooms and data centers
• Cabling for indoor HD surveillance systems
• Indoor network projects in environments with electromagnetic interference
• such as factories and labs
2.Package
• Product main unit
• Standard accessories kit
• User manual
• Color box/Outer carton
