Energy Storage Control Board SMT Service
Turnkey SMT assembly for energy-storage control boards: component sourcing, placement, final assembly and strict AOI/ICT quality control in one delivery.
1.Product Overview
We provide professional turnkey SMT assembly solutions customized for energy-storage control boards. The full-service system covers component sourcing, precision component placement and finished PCBA assembly. With strict AOI and ICT dual quality control standards, we support stable batch production for various energy storage hardware products.
2.Key Features
•Full Turnkey Workflow: Integrates component procurement, SMT placement and final board assembly in one-stop delivery.
•Dual Professional Testing: Equipped with standard AOI optical inspection and ICT in-circuit testing to eliminate production defects.
•Energy Storage Industry Adaptation: Optimized assembly process for high-stability energy storage control board scenarios.
•Scalable Production: Supports prototype trial production and large-scale mass batch manufacturing.
3.Materials & Construction
•Anti-static & Moisture-proof Packaging: Adopts ESD vacuum-sealed moisture-barrier bags, trays and desiccants for product protection.
•Standard Packing Specification: 10 boards per bag, 100 pieces per standard 480×360×300mm master carton.
•Complete Delivery Documents: Provides official inspection reports and full AOI test records for quality traceability.
•Customized Packing Support: Custom labels and exclusive packing lists are available upon customer request.
4.Product Advantages
•Simplified Supply Chain: One-stop turnkey service reduces multi-party coordination and saves procurement & production costs.
•High Quality Stability: AOI+ICT full inspection mechanism ensures low defective rate and consistent product performance.
•Professional Industry Process: Mature SMT manufacturing experience tailored for energy-storage board reliability requirements.
| Item | Parameter |
|---|---|
| Production Line | High-Speed SMT |
| Placement Accuracy | ±0.03mm |
| Component Range | 0201~QFN |
| Production Capacity | 50k pts/h |
| Quality Control | AOI + ICT |
1.Application
•Turnkey SMT assembly service for energy-storage control boards
•Suitable for mass placement and soldering of energy-storage BMS boards, inverter control boards and charge-discharge management boards
•Covers component sourcing, PCBA processing and finished assembly
•Implements full quality inspection via AOI and ICT before delivery
2.Package
•ESD vacuum-sealed moisture-barrier bags, tray packaging and desiccant are adopted
•10 boards per individual bag
•Master carton size: 480×360×300mm, 100 pcs per carton
•Inspection report and AOI records are provided together
•Custom labels and packing lists can be supplied upon request
