17×7.5J Flow-Formed Alloy Wheel 5×120 ET35 in FSB Matte Black
A 17×7.5J flow-formed aluminum alloy wheel with a 5×120 bolt pattern, ET35 offset and 72.6 mm center bore. Its angular split multi-spoke design, CNC-machined mounting features and FSB matte black finish suit compatible passenger-vehicle replacement and styling applications.
Share to:
1. Product Overview
The KU-FV-10-001 is a 17×7.5J flow-formed aluminum alloy wheel featuring a 5×120 bolt pattern, ET35 offset and 72.6 mm center bore. Its angular split multi-spoke layout and FSB matte black finish provide a performance-oriented appearance for compatible passenger vehicles.
Designed for automotive wheel distributors, tuning workshops and aftermarket vehicle-upgrade projects, the wheel is supplied in an individual export carton for international transportation.
2. Flow-Formed Wheel Construction
• Flow-Formed Barrel: The barrel is shaped through a controlled spinning process to refine the wheel structure and support an efficient strength-to-weight design.
• Aluminum Alloy Material: Combines structural performance, corrosion resistance and lower mass compared with many conventional steel-wheel designs.
• Formed Rim Profile: The manufacturing process allows the barrel section to be produced with controlled dimensions and material distribution.
• Street-Use Configuration: Designed for compatible passenger-vehicle replacement and styling applications under suitable load conditions.
3. Split Multi-Spoke Design
• Angular Spoke Layout: The sharply defined split spokes create a technical and performance-oriented appearance.
• Open Spoke Arrangement: Provides visual depth and allows airflow around compatible brake components.
• FSB Matte Black Finish: The low-gloss black coating gives the wheel a restrained, modern appearance.
• Protective Surface Coating: Helps protect the aluminum surface from oxidation and routine environmental exposure.
4. Precision-Machined Fitment Surfaces
• CNC-Machined Bolt Holes: Supports consistent positioning of the wheel-fastener openings.
• Machined Center Bore: Provides a defined mounting interface for vehicles or hub-centric rings using the specified center-bore dimension.
• Controlled Offset: The ET35 offset determines the wheel’s lateral mounting position relative to the vehicle hub.
• Standardized PCD: The 5×120 configuration uses five mounting holes arranged on a 120 mm pitch circle.
5. Vehicle Selection and Installation
• Confirm the vehicle’s required diameter, width, offset, bolt pattern and center-bore specification before ordering.
• Check brake-caliper clearance, suspension clearance and fender clearance using the actual vehicle configuration.
• Confirm the required wheel load rating according to the vehicle’s permitted axle load before installation.
• Use the correct wheel bolts or nuts, thread specification and bolt-seat profile for the selected vehicle and wheel.
• Complete tire mounting, wheel balancing and fastener tightening through a qualified wheel or tire workshop.
• Recheck wheel-fastener torque after the initial driving distance specified by the installer or vehicle manufacturer.
| Item | Parameter |
|---|---|
| SKU | KU-FV-10-001 |
| Item Number | 513 |
| Wheel Diameter | 17 in |
| Rim Width | 7.5J |
| Offset | ET35 |
| Center Bore | 72.6 mm |
| Bolt Pattern | 5×120 |
| Carton Dimensions | 48 × 48 × 24 cm |
| Carton Volume | Approximately 0.06 m³ |
| Product Type | Aftermarket alloy wheel |
| Manufacturing Process | Flow forming |
| Main Material | Aluminum alloy |
| Spoke Design | Angular split multi-spoke |
| Finish | FSB matte black |
| Machining | CNC-machined bolt holes and center bore |
| Vehicle Application | Selected passenger vehicles with compatible wheel specifications |
| Fitment Verification | Confirm PCD, center bore, offset, rim width, load rating, brake clearance and fastener type before ordering |
Fitment and Safety Notice
Matching the 5×120 bolt pattern alone does not confirm vehicle compatibility. Center bore, offset, rim width, brake clearance, wheel-load rating, fastener seat and tire specification must also be verified by a qualified installer. Do not install the wheel if its load rating or vehicle compatibility has not been confirmed.
1. Applications
• Wheel replacement
• Vehicle customization
• Automotive wheel retail
• Tuning workshop projects
• Alloy-wheel distribution
• Passenger-vehicle styling upgrades
• Vehicles requiring compatible 17×7.5J, ET35 and 5×120 specifications
2. Package
Packing Information
• Quantity: 1 pc
• Packaging: Individual export carton
• Carton Size: 48 × 48 × 24 cm
• Carton Volume: Approximately 0.06 m³
