10W 18V Polycrystalline Solar Panel with Aluminum Frame
A compact 10W polycrystalline solar panel for small 12V battery charging systems. It has an aluminum frame, measures 334 × 203 × 16 mm, and should be paired with a suitable solar charge controller when charging a battery.
Share to:
1. A small panel for 12V battery systems
This 10W polycrystalline solar panel is intended for applications with modest power requirements, such as maintaining a small 12V battery. The supplied product information lists an 18V panel voltage and a nominal 12V system voltage. Use a charge controller matched to the panel and battery rather than connecting the panel directly to the battery.
2. Aluminum-framed construction
At 334 × 203 × 16 mm, the panel is compact enough for installations where a larger module would be unnecessary. It has an aluminum frame and weighs 0.46 kg according to the supplied specifications.
3. Choosing the right setup
A 10W panel is suited to low-power charging tasks, not to running household appliances or charging a large battery quickly. Before ordering, check the battery size, expected power use and charge-controller requirements against the panel’s specifications.
| Parameter | Specification |
|---|---|
| Product Type | Aluminum-framed polycrystalline solar panel |
| Rated Power | 10 W |
| Stated Panel Voltage | 18 V DC |
| Nominal System Voltage | 12 V DC |
| Solar Cell Type | Polycrystalline |
| Stated Conversion Efficiency | 23–24% |
| Frame | Aluminum |
| Panel Dimensions | 334 × 203 × 16 mm |
| Listed Weight | 0.46 kg |
| Operating Temperature | -40°C to +85°C |
| Individual Package Dimensions | 350 × 210 × 40 mm |
Applications
- Small 12V battery maintenance systems
- Low-power off-grid charging setups
Package Contents
- Solar panel × 1
- User manual × 1
